A pale swept wing-root panel on a long dark carbon tube, a three-blade propeller on a motor at each end of the tube, and a dark printed mount hanging under each motor, with a short raised code on the side of the dark mount under the right-hand motor., ivory colourwayA pale swept wing-root panel on a long dark carbon tube, a three-blade propeller on a motor at each end of the tube, and a dark printed mount hanging under each motor, with a short raised code on the side of the dark mount under the right-hand motor., green colourway

The port VTOL Section of Fuselage C v2.4B on its 14 mm spar: the lightweight-PLA Section with its PETG Section Plate at the wing joint and our Wing Clip in its pocket, the PETG Spar Mount and the TPU wire window cover, an EMAX ECO II 2807 with its Gemfan F8041 3-blade prop and M5 nut at each end of the spar, and under the Section the two PETG gear mounts of keel B, the bolt-pilot stilt mount forward and the cable-riser keel mount aft, which take the place of motor mounts (th-blender W84); the part mark K01P-B raised on the keel mount's outboard face (th-blender W129).
