J2, the split bulkhead

A close view of a dark printed bracket on a grey wall, seen from inboard and above, with a gold connector jack through it and a green circuit board below; a black coax lead runs off to the left, and at the right a second dark bracket carries a round disc with a hole at its centre; a black cable crosses the picture from the lower left to the upper right., ivory colourwayA close view of a dark printed bracket on a grey wall, seen from inboard and above, with a gold connector jack through it and a green circuit board below; a black coax lead runs off to the left, and at the right a second dark bracket carries a round disc with a hole at its centre; a black cable crosses the picture from the lower left to the upper right., green colourway

Joint J2 on the port wall, seen from inboard and above with the bay wall hidden: the single split J2 bracket and its SMA bulkhead jack, with a hex pocket on the radio side and a washer and nut on the plug side, and hub A's pad with its clips and the two Micro BECs (th-blender W74b). At the right edge is the Trim Bracket on the Front's port wall, its round washer seat facing aft (th-blender W100.1). A black cable bundle, the VTX harness lane (W127.1, an estimate), crosses the view from the lower left to the upper right.

Series
Details
Engine
Cycles
Resolution
2400 × 1500
Source
blender/renders/22-detail-j2-bulkheads-cycles.png
Full size, greenFull size, ivory
